Start with the metal, not the tools

Before you reach for a mallet, think about the sheet. Mild steel, aluminium, stainless and copper all bend differently. For small projects, 0.8 mm to 1.5 mm sheet is comfortable to fold by hand with simple jigs. Much thicker than 2 mm and you'll need heat, a heavier former, or a helper. Check the temper: soft aluminium bends easily, while half-hard grades crack if forced. Anneal aluminium by marking it with soot or permanent marker, heating until the mark disappears, then cooling slowly. Mild steel usually bends without fuss, but stainless work-hardens quickly and needs a larger radius. As a rule, the inside radius should be at least the sheet thickness for mild steel, and one to two times the thickness for aluminium. Mark your bend line with a scriber or fine marker. Avoid deep scratches across the bend—they become crack starters.

Hand tools and a solid bench

You don't need a press brake, but you do need a stable bench and a few reliable tools. A sturdy vice is essential, ideally with smooth jaws or jaw caps. For folding, collect:

• Two lengths of clean angle iron, 25 mm x 25 mm or larger, at least 300 mm long.
• A soft-faced mallet—nylon or rubber—plus a dead-blow mallet for controlled taps.
• Several G-clamps or F-clamps. Cheap clamps slip; buy or borrow decent ones.
• Hardwood or MDF offcuts for formers, jaw pads and cauls.
• A steel rule, engineer's square, protractor or angle finder, and a scriber.
• Files and deburring tools. Sharp edges are the enemy of neat work.

Wear eye protection and gloves when handling sheet. Deburr every cut edge before you bend. A clean edge folds more predictably and saves your hands.

The vice, two bars and a mallet

This is the classic manual fold. Clamp your sheet between two pieces of angle iron in the vice, with the bend line aligned exactly with the front edge of the angle. If you're bending a narrow strip, use a third clamp in the middle to stop the metal creeping. Tighten firmly—but not so hard that you emboss the sheet. Now tap the protruding sheet over with your soft mallet. Don't hit it once in the middle. Start at one end and work along the bend line with overlapping blows, letting the angle iron act as your anvil. For a 90-degree bend, fold until the sheet touches the vertical face of the angle. Then check with a square. Metal springs back, so you'll often need to overbend by a few degrees and ease it back. For long bends, two people make life easier: one holds the sheet, one taps. If the metal starts to ripple, stop and clamp closer to the bend line.

Build a simple folding jig

A dedicated folding jig turns messy hand-bending into repeatable work. You can make one from two pieces of angle iron and a piano hinge. Bolt one angle to a sturdy board or bench as the fixed jaw. Attach the second angle to the first with a piano hinge along the back edge, so the top angle opens and closes like a book. Clamp your sheet between the jaws, aligning the bend line with the hinge line. Lift the top angle by hand or with a wooden lever, and the sheet folds neatly. Add a handle made from a length of timber for extra leverage. For boxes, trays and brackets, make a plywood or MDF former in the shape of the finished corner. Clamp the sheet over the former and hammer the edge down with a mallet. Work slowly from the centre outwards. A set of formers in 5 mm, 10 mm and 20 mm radii will cover most small projects. Keep the jig clean; a stray metal chip will leave a dent in your fold.

Curves, cylinders and hammer forming

Gentle curves and small cylinders are easier than they look. For a curved panel, cut a hardwood or MDF former to the required radius, clamp the sheet over it, and tap the metal down with a soft mallet. Move the clamp along as you go, and anneal aluminium if it starts to harden. For a cylinder, find a piece of pipe or a gas cylinder with the right diameter. Clamp the pipe in the vice, lay the sheet over it, and press down with a block of wood while tapping the edges. Roll the sheet back and forth, applying pressure with your hands or a wooden block. Jubilee clips or hose clamps can hold the rolled shape while you adjust the seam. Don't try to roll a full cylinder in one pass. Take it slowly, working from the middle outwards. If the metal kinks, flatten it gently and start again with a larger radius.

Accuracy, springback and finishing touches

Springback is the reason your first fold looks underdone. Every metal returns slightly after bending, so aim past your target angle. For a 90-degree bend, try 92 to 95 degrees, then check with a square. Make a test piece from the same material and thickness before you commit to the final job. Measure the flange lengths after bending, not before—bend allowance means the flat pattern is shorter than the sum of the outside dimensions. For a simple 90-degree bend, a useful starting point is to subtract one material thickness from each flange length, then adjust after a trial fold. Use masking tape as a bend line guide if you struggle to see scribe marks. Work on a clean surface, deburr after bending, and store finished parts flat. With a little practice, a vice, a mallet and a homemade jig will handle most small sheet metal folds neatly and accurately. And remember: if a bend goes wrong, most mild steel and aluminium can be flattened and bent again once—work carefully, and you'll rarely need to.
